Power Relay, 120A, Standard, Bistable, 2 Coils, Polarized

Power Relay, 120A, Standard, Bistable, 2 Coils, Polarized-CAT-AL6-KSPR30120
The Series 30 120A bi-stable relay is polarized, featuring two coils and 6G shock and 4G vibration resistance. Sealed housing conforms to IP67 and IP6K9K.
More Less

Product Features

  • Relay Type: Standard

  • Coil Magnetic System: Bistable, 2 Coils, Polarized

  • Coil Resistance(Ω): 10

  • Coil Special Features: None

  • Coil Voltage Rating(VDC): 18, 32

Available from

LADD Inc

Overview

KISSLING Single Pole Bi-Stable Relays

Series 30 / 120A

The series 30 bi-stable relay meets even the most difficult operating requirements and is suited for various applications in severe conditions on commercial vehicles, buses, construction & agricultural vehicles, ground support equipment and fork lifts. These relays are available with a wide variety of configuration options including different contact configurations and coil voltages to have the right product for your needs.

Key Features

  • Sealed housing conforms to IP6K9K
  • Robust design
  • Variety of configuration options
  • 6G shock and 4G vibration resistant
  • Main contact current rated for continuous current and 100% duty cycle

Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

  • Relay Type  Standard

Configuration Features

  • Coil Special Features  Coil Suppression Diode, None

  • Contact Arrangement  1 Form X (SPST-NO-DM)

  • Contact Number of Poles  1

Electrical Characteristics

  • Coil Power Rating DC (mW) 51, 57, 64

  • Coil Resistance (Ω) 2.5 – 2.8, 9 – 10, 10

  • Coil Voltage Rating (VDC) 9, 16, 18, 32

  • Contact Current Rating (A) 120

  • Contact Voltage Rating (VDC) 12, 24

Contact Features

  • Contact Material  AgSnO2

Termination Features

  • Relay Connection Type  Terminals

  • Terminal Configuration  Screw Terminals

Mechanical Attachment

  • Product Mount Type  Panel

  • Product Mounting Feature Type  Flange with Mounting Slots

Dimensions

  • Product Height  75 mm [ 2.95 in ]

  • Product Length  68 mm [ 2.67 in ]

  • Product Width  45 mm [ 1.77 in ]

Operation/Application

  • Coil Magnetic System  Bistable, 2 Coils, Polarized

Other

  • Contact Current Class (A) 120

Reference Number

  • TE Internal Number CAT-AL6-KSPR30120
