Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Seal & Plug Type : Gasket

• RF Interface : N Type

• RF Connector Style : Plug

• Compatible With RF Cable Type : KX 24, Raychem 5012F3332, URM 91, KX 13, Raychem 5012A3422, RG 214, RG 9B

• Connector System : Cable-to-Cable

• Sealable : Yes

• Connector & Contact Terminates To : Wire & Cable

• RF Connector Contact Configuration : Captivated Contacts

• Crimp Type : Hexagonal Crimping

• Ferrule Material : Annealed Copper

• Ferrule Plating Material : Nickel

• RF Connector Center Contact Plating Material : Gold

• RF Connector Center Contact Material : Brass

• Grade : Commercial

• Gasket Material : Silicone Rubber

• Coupling Nut Base Material : Brass

• Dielectric Material : PTFE

• EU RoHS Compliance : Compliant with Exemptions

• EU ELV Compliance : Compliant with Exemptions

• Packaging Quantity : 50

• Packaging Method : Box

• RF Connector Mated Outer Diameter (Approximate) : 19.05 mm [ .75 in ]

• Impedance (Ω): 50

• RF Connector Coupling Mechanism : Threaded

• RF Contact Captivation Method : Mechanical

• Detent : Without

• Operating Frequency (GHz): 11

• Number of Positions : 1

• Number of Coaxial Contacts : 1

• Cable Connector Orientation : Straight

• Body Material : Brass

• Body Plating Material : Nickel

• Termination Method to Wire & Cable : Crimp
