Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Blank Cavity Position : 5

• Number of Positions : 6

• Number of Rows : 1

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Board, Wire-to-Device, Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Contact Type : Receptacle

• Contact Size : .64mm

• Mating Tab Width : .64 mm [ .025 in ]

• Housing Material : PA GF

• Centerline (Pitch) : 2.54 mm [ .1 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Connector & Keying Code : A

• Serviceable : Yes

• Connector Position Assurance Capable : Yes

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Package

• Packaging Quantity : 600

• Connector Height : 19.6 mm [ .772 in ]

• Product Length : 31.4 mm [ 1.236 in ]

• Product Width : 24.5 mm [ .965 in ]

• IP Rating : IP67

• Operating Temperature (Max) (°C): 125

• Operating Temperature (Max) (°F): 248, 221, 158, 167, 230, 176, 194, 185, 212, 257

• Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]
