Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Wire & Cable

• Connector Shape : Rectangular

• Connector & Housing Type : Housing for Female Terminals

• Primary Locking Feature : Integrated in Housing

• Sealable : No

• Connector System : Wire-to-Wire

• Mixed & Hybrid Connector : No

• Number of Positions : 4

• Number of Rows : 1

• Operating Voltage (VDC): 14

• Nominal Voltage Architecture (V): 12, 14

• Primary Product Color : Yellow

• Cable Exit Angle : 180°

• Mating Tab Width : .63 mm [ .025 in ]

• Contact Size : .63mm

• Contact Type : Receptacle

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Alignment Type : Polarized

• Terminal Position Assurance : No

• Mating Alignment : With

• Strain Relief : Without

• Housing Material : PBT GF

• Centerline (Pitch) : 2.54 mm [ .1 in ]

• Product Width : 11.5 mm [ .452 in ]

• Connector Height : 17.6 mm [ .692 in ]

• Product Length : 12.4 mm [ .488 in ]

• Circuit Application : Signal

• Compatible With Agency/Standards Products : DIN IEC 512

• Packaging Method : Tray

• Packaging Quantity : 750
