Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Contact Type : Receptacle

• Contact Size : .64mm, 1.5mm

• Mating Tab Width (mm): 1.5, .64

• Mating Tab Width (in): .025, .059

• Housing Material : PA GF

• Centerline (Pitch) (mm): 5.08, 2.54

• Centerline (Pitch) (in): .1, .2

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Connector & Keying Code : C

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : Add By Accessory

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Package

• Packaging Quantity : 40

• Connector Height : 46.5 mm [ 1.831 in ]

• Product Length : 40.8 mm [ 1.606 in ]

• Product Width : 52.9 mm [ 2.083 in ]

• Row-to-Row Spacing : 4.7 mm [ .185 in ]

• IP Rating : IP67

• Number of Positions : 50

• Number of Rows : 1, 4

• Operating Temperature (Max) (°C): 125

• Operating Temperature (Max) (°F): 248, 221, 167, 158, 230, 176, 194, 185, 212, 257

• Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]
