• Connector Shape : Rectangular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : 2.8mm, 1.5mm

• Mating Tab Width (mm): 2.8, 1.5

• Mating Tab Width (in): .06, .11

• Contact Current Rating (Max) (A): 30, 15

• Housing Material : PBT GF

• Centerline (Pitch) (mm): 5.7, 6.7

• Centerline (Pitch) (in): .22, .26

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Connector & Keying Code : A

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Box & Tray

• Packaging Quantity : 56

• Connector Height : 34.2 mm [ 1.34 in ]

• Product Length : 36.1 mm [ 1.42 in ]

• Product Width : 36.8 mm [ 1.44 in ]

• Row-to-Row Spacing : 5.75 mm [ .22 in ]

• Number of Positions : 12

• Number of Rows : 3
