Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Number of Positions : 2

• Number of Rows : 1

• Operating Voltage (VDC): 13

• Nominal Voltage Architecture (V): 13

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Connector & Keying Code : Neutral

• Contact Type : Receptacle

• Contact Size : 8mm

• Mating Tab Width : 8 mm [ .314 in ]

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Housing Material : PBT

• Centerline (Pitch) : 12 mm [ .472 in ]

• Connector Height : 29.8 mm [ 1.173 in ]

• Product Length : 34.6 mm [ 1.362 in ]

• Product Width : 29.8 mm [ 1.173 in ]

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]

• Circuit Application : Signal

• UL Flammability Rating : UL 94HB

• IP Rating : IP67

• Packaging Method : Box

• Packaging Quantity : 750
