Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Wire & Cable

• Connector Shape : Rectangular

• Connector & Housing Type : Housing for Female Terminals

• Primary Locking Feature : Integrated in Housing

• Sealable : Yes

• Connector System : Wire-to-Wire

• Mixed & Hybrid Connector : No

• Number of Positions : 4

• Number of Rows : 2

• Primary Product Color : Black

• Connector & Keying Code : A

• Cable Exit Angle : 180°

• Mating Tab Width : .63 mm [ .025 in ]

• Contact Size : .63mm

• Contact Type : Receptacle

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Mating Alignment : With

• Strain Relief : Without

• Housing Material : PBT GF15

• Centerline (Pitch) : 6.2 mm [ .25 in ]

• Product Width : 26 mm [ 1.02 in ]

• Connector Height : 15.3 mm [ .602 in ]

• Product Length : 26 mm [ 1.02 in ]

• Row-to-Row Spacing : 2.54 mm [ .1 in ]

• Packaging Method : Carton

• Packaging Quantity : 1500
