Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• UL Rating : Recognized

• Compatible With Approved Standards Products : UL E28476

• Compatible With Agency/Standards Products : UL, VDE

• UL Flammability Rating : UL 94V-2

• Glow Wire Rating : GWT 750°C (Without Flame)

• Panel Mount Feature : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Multiple Contact Types : Without

• Contact Retention Within Housing : Without

• Contact Type : Pin

• Packaging Quantity : 1

• Packaging Method : Bag

• Rectangular Power Connector Type : Housing

• Connector & Housing Type : Receptacle

• Connector System : Wire-to-Wire

• Sealable : No

• Connector & Contact Terminates To : Wire & Cable

• Number of Positions : 1

• Number of Rows : 1

• Operating Voltage (VAC): 600

• Termination Method to Wire & Cable : Crimp

• Housing Color : Natural

• Housing Material : PA 6

• Operating Temperature Range : -55 – 105 °C [ -67 – 221 °F ]

• Circuit Application : Power & Signal
