1986469-5
5 Position Barrier Strip, Wire-to-Wire, 14.5 mm [.571 in] Centerline, 1 Row, Operating Voltage 600 V, 14 – 6 AWG Wire Size, 2 – 14 mm² Wire Size
1986469-5
5 Position Barrier Strip, Wire-to-Wire, 14.5 mm [.571 in] Centerline, 1 Row, Operating Voltage 600 V, 14 – 6 AWG Wire Size, 2 – 14 mm² Wire Size
-
- Europa
- TE Internal #: 1986469-5
- TE Internal Description: TSB2000K05DSHT=EUROPA BL,14.5M
-
Number of Positions : 5
-
Connector System : Wire-to-Wire
-
Centerline (Pitch) : 14.5 mm [ .571 in ]
-
Number of Rows : 1
-
Operating Voltage (V): 600
Documents
Product Drawings
- 14.5MM PITCH WIRE PROTECTOR 65A HIGH VOLTAGE VERSION, HIGH TEMP ENG_CD_1986469_A3.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_1986469-5_A.pdf 3D
- Customer View Model ENG_CVM_CVM_1986469-5_A.2d_dxf.zip English
- ENG_CVM_CVM_1986469-5_A.3d_igs.zip English
- ENG_CVM_CVM_1986469-5_A.3d_stp.zip English
Datasheets & Catalog Pages
- BUCHANAN TERMINAL BLOCKS CATALOG - BARRIER STRIPS ENG_CS_1308389_BARRIER_STRIPS_2110.pdf English
