Please review product documents or contact us for the latest agency approval information.

• Connector Shape : Circular

• Connector & Housing Type : Housing for Female Terminals

• Primary Locking Feature : On the Terminal

• Sealable : Yes

• Connector System : Wire-to-Board, Wire-to-Device

• Mixed & Hybrid Connector : No

• Number of Positions : 2

• Number of Rows : 2

• Nominal Voltage Architecture (V): 12, 24, 42, 48

• Primary Product Color : Gray

• Connector & Keying Code : 2

• Cable Exit Angle : 180°

• Mating Pin Diameter : 2.5 mm [ .098 in ]

• Contact Size : 2.5mm

• Contact Type : Socket

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Mating Alignment : With

• Housing Material : PBT GF

• Centerline (Pitch) : 7 mm [ .276 in ]

• Product Width : 31 mm [ 1.22 in ]

• Connector Height : 32.9 mm [ 1.29 in ]

• Product Length : 32.9 mm [ 1.29 in ]

• Operating Temperature Range : -40 – 120 °C [ -40 – 248 °F ]

• Operating Temperature (Max) (°C): 70, 75, 80, 85, 90, 100, 105, 110, 120

• Operating Temperature (Max) (°F): 158, 167, 176, 185, 194, 212, 221, 230, 248

• IP Rating : IP69K

• UL Flammability Rating : UL 94HB

• Packaging Method : Bag

• Packaging Quantity : 100
