Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Circular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Male Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Pin

• Contact Size : 2.5mm

• Mating Pin Diameter : 2.5 mm [ .098 in ]

• Housing Material : PBT GF

• Centerline (Pitch) : 7 mm [ .276 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Gray

• Connector & Keying Code : 2

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Quantity : 450

• Packaging Method : Box

• Connector Height : 28 mm [ 1.1 in ]

• Product Length : 44 mm [ 1.73 in ]

• Row-to-Row Spacing : 7 mm [ .276 in ]

• UL Flammability Rating : UL 94HB

• IP Rating : IP69K

• Number of Positions : 4

• Number of Rows : 2

• Nominal Voltage Architecture (V): 24, 42, 48, 12

• Operating Temperature (Max) : 120 °C [ 248 °F ]

• Operating Temperature Range : -40 – 120 °C [ -40 – 248 °F ]
