Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : On the Terminal

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : .63mm

• Mating Tab Width : .63 mm [ .025 in ]

• Contact Current Rating (Max) (A): 7.5

• Housing Material : PBT GF

• Centerline (Pitch) : 6.2 mm [ .244 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Gray

• Connector & Keying Code : B

• Operating Voltage (VDC): 50

• Nominal Voltage Architecture (V): 50

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Bag

• Packaging Quantity : 1700

• Connector Height : 24.2 mm [ .953 in ]

• Product Length : 23.2 mm [ .913 in ]

• Product Width : 15.3 mm [ .602 in ]

• Row-to-Row Spacing : 6 mm [ .236 in ]

• Number of Positions : 4

• Number of Rows : 2

• Operating Temperature (Max) (°C): 80, 105, 100, 90, 85, 75, 70, 110, 120

• Operating Temperature (Max) (°F): 248, 221, 158, 167, 230, 176, 194, 185, 212

• Operating Temperature Range : -40 – 120 °C [ -40 – 248 °F ]
