Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Power Component Application Type : Outdoor Use, Indoor Use

• Mechanical Connector Product Type : Shear Bolt Terminal Lug

• Stud Size : M12

• Installation Technology : Shear Bolt

• Bolt Head Size (Across Flats) (mm): 15

• Inside Diameter Range : 15.8 mm [ .62 in ]

• Compatible Conductor Range (AWG/kcmil): 4 – 4/0

• Compatible Conductor Cross-Section Range (mm²): 16 – 95, 25 – 95

• Palm Hole Diameter : 13

• Compatible With Approved Standards Products : IEC 61238-1 Class A

• Voltage Class (kV): ≤ 84

• Compatible Conductor Material : Copper, Aluminum

• Conductor Type : Sector, Stranded

• Primary Product Material : Aluminum

• Number of Bolts : 2

• Conductor Gauge Type : Metric

• EU RoHS Compliance : Compliant with Exemptions

• EU ELV Compliance : Compliant with Exemptions
