Please review product documents or contact us for the latest agency approval information.

• Connector Seal & Plug Type : Peripheral

• Connector Product Type : Housing

• Connector System : Wire-to-Wire

• Sealable : Yes

• Connector & Contact Terminates To : Wire & Cable

• Connector & Housing Type : Receptacle

• Circular Connector Shell Type : All Plastic

• Reverse Numbering : Without

• Number of Positions : 9

• Number of Power Positions : 0

• Number of Signal Positions : 9

• Operating Voltage (VDC): 600

• Operating Voltage (VAC): 600

• Reverse Gender : No

• Contact Type : Pin

• Contact Current Rating (Max) (A): 13

• Contact Protection : With

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Panel Mount Feature Type : Flange

• Polarization Code : A

• Thread Size : 3/4 - 20 UNEF-2A

• Mating Retention Type : Threaded Coupling

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Retention : With

• Panel Mount Feature : Without

• Body Orientation : Straight

• Housing Color : Black

• Housing Material : PA 6.6 GF

• Circular Connector Shell Size : 13

• Operating Temperature Range : -55 – 105 °C [ -67 – 221 °F ]

• Fluid Resistance : Immersion

• Circuit Application : Signal

• Shielded : No

• UL Flammability Rating : UL 94V-0
