Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Coating Style : Inline

• Installation Technology : Heat Shrink

• Adhesive Coating : With

• Wall Style (Excluding Adhesive) : Single

• Primary Product Material : Crosslinked Polyolefin

• Primary Product Color : Gray

• Flexibility : Semi-Flexible

• Shrink Ratio : > 3:1

• Compatible Cable Diameter (Max) : 17 mm [ .669 in ]

• Compatible Cable Diameter (Min) : 6.5 mm [ .255 in ]

• Expanded Inside Diameter (Min) (mm): 19

• Recovered Inside Diameter (Max) (mm): 6

• Product Length (mm): 1000

• Recovered Wall Thickness (Max) (mm): 2.4

• Wall Thickness : Thick/Heavy

• Environmental Resistance : Contaminated Water, Moisture, Rain, Salt Water, Weathering

• Flammability Performance : Flame-Retardant

• Thermal Resistance : Applicable for Low Temperatures, Flame-Retardant

• Marine-Offshore-Shipbuilding Certified : No

• UV-Stabilized : Yes

• Mechanical Resistance : Abrasion Resistant, Against Mechanical Impact or Damage

• Compatible With Approved Standards Products : HD631.2, IEC 60684-3-165, IEC 60684-3-216, IEC 60684-3-248
