2195873-1
Flexible PCB (FPC) Antenna, Multi Band, Cellular / GNSS / LTE, External Mount, Connector, Omnidirectional, Single Port, Gain 3 < 6 dBi
2195873-1
Flexible PCB (FPC) Antenna, Multi Band, Cellular / GNSS / LTE, External Mount, Connector, Omnidirectional, Single Port, Gain 3 < 6 dBi
- TE Internal #: 2195873-1
- TE Internal Description: LEMBAS LTE GNSS USB Modem
-
Packaging Method : Box
-
Mounting Type : Connector
-
Antenna Type : Flexible PCB (FPC)
-
Applicable Region : Americas
-
Port Configuration : Single Port
Documents
Product Drawings
- ASSY, USB DONGLE, ENG_CD_2195873_A.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_2195873-1_1.pdf 3D
- Customer View Model ENG_CVM_CVM_2195873-1_1.2d_dxf.zip English
- ENG_CVM_CVM_2195873-1_1.3d_igs.zip English
- ENG_CVM_CVM_2195873-1_1.3d_stp.zip English
Datasheets & Catalog Pages
- Instructions Manual LEMBAS ENG_DS_2195873_Instructions_Manual_A1.pdf English
Product Specifications
- Product Specification ENG_SS_108-160357_A3.pdf English
Instruction Sheets
- Instruction Sheet (U.S.) ENG_SS_Instructions_Manual_LEMBAS_2403.pdf English
