Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Board, Wire-to-Device

• Sealable : No

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : .5mm

• Mating Tab Width : .5 mm [ .02 in ]

• Housing Material : PBT GF

• Centerline (Pitch) : 1.8 mm [ .071 in ]

• Operating Voltage (VDC): 12

• Nominal Voltage Architecture (V): 12

• Serviceable : Yes

• Connector Position Assurance Capable : Yes

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Connector Height (mm): 6.65

• Product Length (mm): 15.25

• Product Width (mm): 15.5

• Compatible With Agency/Standards Products : SAE/USCAR-2

• Number of Positions : 2

• Number of Rows : 1

• Primary Product Color : Black

• Connector & Keying Code : C

• Operating Temperature (Max) : 100 °C [ 212 °F ]

• Operating Temperature Range : -40 – 100 °C [ -40 – 212 °F ]
