2354883-1
58 Position Housing, Housing for Female Terminals, 3.8 mm / 7 mm [.149 in / .275 in] Centerline, Sealable, Blue, Wire & Cable, MCON 1.2mm
2354883-1
58 Position Housing, Housing for Female Terminals, 3.8 mm / 7 mm [.149 in / .275 in] Centerline, Sealable, Blue, Wire & Cable, MCON 1.2mm
-
- MCON
- MCON 1.2mm
- TE Internal #: 2354883-1
- TE Internal Description: 58POS,MCON 1.2 CB,REC HSG,ASSY
-
Number of Positions : 58
-
Connector & Housing Type : Housing for Female Terminals
-
Mating Tab Width (mm): 1.2, 2.8
-
Mating Tab Width (in): .047, .11
-
Centerline (Pitch) (mm): 3.8, 7
-
Centerline (Pitch) (in): .149, .275
-
Sealable : Yes
Documents
Product Drawings
- FEMALE HOUSING ASSEMBLY, 58 WAY ABS CONNECTOR ENG_CD_2354883_A2.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_2354883-1_A.pdf 3D
- Customer View Model ENG_CVM_CVM_2354883-1_A.3d_stp.zip English
- ENG_CVM_CVM_2354883-1_A.3d_igs.zip English
- ENG_CVM_CVM_2354883-1_A.2d_dxf.zip English
Product Specifications
- Application Specification ENG_SS_114-94240_D.pdf English
