Please review product documents or contact us for the latest agency approval information.

• PCB Connector Type : PCB Mount Header

• Connector System : Wire-to-Board

• Sealable : No

• Connector & Contact Terminates To : Printed Circuit Board

• Connector Product Type : Connector Assembly

• PCB Mount Orientation : Vertical

• Number of Positions : 3

• Number of Rows : 1

• Connector & Keying Code : A

• Primary Product Color : Natural

• Contact Mating Area Plating Material Finish : Bright

• Contact Mating Area Plating Material Thickness : 2 µm [ 80 µin ]

• Contact Mating Area Plating Material : Tin (Sn)

• Contact Type : Pin

• Contact Current Rating (Max) (A): 2.2

• Termination Method to PCB : Surface Mount

• PCB Mount Alignment Type : Pegs

• Mating Retention : With

• PCB Mount Retention : Without

• PCB Mount Alignment : With

• Connector Mounting Type : Board Mount

• Mating Alignment : Without

• Housing Material : Nylon

• Centerline (Pitch) : 2 mm [ .079 in ]

• Operating Temperature Range : -40 – 105 °C [ -40 – 221 °F ]

• Circuit Application : Signal

• UL Flammability Rating : UL 94V-0
