2375555-2
8 Position Housing, Housing for Female Terminals, Wire-to-Wire, 4.7 mm [.185 in] Centerline, Sealable, Black, Wire & Cable, Power, Superseal Pro
2375555-2
8 Position Housing, Housing for Female Terminals, Wire-to-Wire, 4.7 mm [.185 in] Centerline, Sealable, Black, Wire & Cable, Power, Superseal Pro
-
- AMP
- Superseal Pro
- TE Internal #: 2375555-2
- TE Internal Description: 8POS,MCON 1.2,REC HSG ASSY,SLD,COD B
-
Number of Positions : 8
-
Connector & Housing Type : Housing for Female Terminals
-
Mating Tab Width : 1.2 mm [ .047 in ]
-
Connector System : Wire-to-Wire
-
Centerline (Pitch) : 4.7 mm [ .185 in ]
Documents
Product Drawings
- SUPERSEAL PRO 8POS,PLUG ASSEMBLY MCON1.2,CB TEMINAL ENG_CD_2375555_A2.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_2375555-2_A.pdf 3D
- Customer View Model ENG_CVM_CVM_2375555-2_A.2d_dxf.zip English
- ENG_CVM_CVM_2375555-2_A.3d_igs.zip English
- ENG_CVM_CVM_2375555-2_A.3d_stp.zip English
Product Specifications
- Application Specification ENG_SS_114-32258_B1.pdf English
- Product Specification ENG_SS_108-32189_A.pdf English
- ENG_SS_108-32189_A_B.pdf English
