Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Adhesive Coating : With

• Installation Technology : Heat Shrink

• Coating Style : Inline

• Wall Style (Excluding Adhesive) : Single

• Primary Product Color : Gray

• Flexibility : Semi-Flexible

• Primary Product Material : Crosslinked Polyolefin

• Shrink Ratio : > 3:1

• Recovered Wall Thickness (Max) (mm): 4.1

• Compatible Cable Diameter (Min) : 24 mm [ .944 in ]

• Compatible Cable Diameter (Max) : 61 mm [ 2.401 in ]

• Wall Thickness : Thick/Heavy

• Product Length (mm): 1200

• Environmental Resistance : Salt Water, Weathering, Moisture, Contaminated Water, Rain

• Flammability Performance : Flame-Retardant

• Mechanical Resistance : Abrasion Resistant, Against Mechanical Impact or Damage

• UV-Stabilized : Yes

• Thermal Resistance : Applicable for Low Temperatures, Flame-Retardant

• Marine-Offshore-Shipbuilding Certified : No

• Compatible With Approved Standards Products : HD631.2, IEC 60684-3-165, IEC 60684-3-248, IEC 60684-3-216
