Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Wire & Cable

• Connector Shape : Rectangular

• Connector & Housing Type : Housing for Female Terminals

• Primary Locking Feature : On the Terminal

• Sealable : Yes

• Connector System : Wire-to-Wire

• Mixed & Hybrid Connector : Yes

• Number of Positions : 15

• Number of Rows : 2

• Operating Voltage (VDC): 60

• Primary Product Color : Black

• Connector & Keying Code : D

• Cable Exit Angle : 90°, 180°

• Mating Tab Width (mm): 1.5, 2.8

• Mating Tab Width (in): .059, .11

• Contact Current Rating (Max) (A): 40

• Contact Size : 2.8mm, 1.5K

• Contact Type : Receptacle

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Mating Alignment : With

• Strain Relief : Without

• Housing Material : PBT GF30

• Centerline (Pitch) (mm): 4, 6

• Centerline (Pitch) (in): .157, .236

• Product Width : 25.7 mm [ 1.012 in ]

• Connector Height : 31.25 mm [ 1.23 in ]

• Product Length : 67.2 mm [ 2.646 in ]

• Operating Temperature Range : -40 – 140 °C [ -40 – 284 °F ]

• Operating Temperature (Max) : 140 °C [ 284 °F ]

• Circuit Application : Power

• UL Flammability Rating : UL 94V-0

• Degree of Protection : IP67

• Packaging Method : Carton

• Packaging Quantity : 140
