Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Wire & Cable

• Connector & Housing Type : Receptacle

• Sealable : No

• Rectangular Power Connector Type : Connector Assembly

• Connector System : Wire-to-Board

• Compatible With Discrete Wire Type : Stranded

• Number of Rows : 1

• Number of Power Positions : 11

• Number of Positions : 11

• Operating Voltage (VAC): 600

• Connector Profile : Standard

• Cable Exit Angle : 90°

• Contact Underplating Material Thickness : 30 µm [ .762 µin ]

• Wire Contact Termination Area Plating Thickness : 2.03 µm [ 80 µin ]

• Contact Base Material : Copper Alloy

• Contact Underplating Material : Nickel

• Contact Current Rating (Max) (A): 7

• Contact Type : Receptacle

• Contact Layout : Inline

• Contact Mating Area Plating Material Thickness : 2.03 – 5.08 µm [ 80 – 200 µin ]

• Contact Mating Area Plating Material Finish : Matte

• Wire Contact Termination Area Plating Material : Tin

• Contact Retention Within Housing : With

• Contact Mating Area Plating Material : Tin

• Termination Method to Wire & Cable : Insulation Displacement (IDC)

• Connector Mounting Type : Cable Mount (Free-Hanging)

• PCB Mount Alignment : Without

• Strain Relief : With

• Mating Alignment Type : Polarizing Tab

• PCB Mount Retention : Without

• Mating Alignment : With

• Contact Retention Type Within Housing : Locking Lance

• Panel Mount Feature : Without

• Mating Retention : With

• Mating Retention Type : Locking Ramp

• Centerline (Pitch) : 3.96 mm [ .156 in ]

• Housing Color : Yellow

• Housing Material : Nylon

• Wire & Cable IDC Installation Type : Closed End

• Connector Height (mm): 9.02

• Compatible Insulation Diameter Range : 2.41 mm [ .095 in ]

• Wire Size (AWG): 20

• Product Length (mm): 43.59

• Wire Size (mm²): .517

• Operating Temperature Range : -55 – 105 °C [ -67 – 221 °F ]

• Circuit Application : Power

• Compatible With Approved Standards Products : UL E28476

• Compatible With Agency/Standards Products : CSA, UL

• UL Flammability Rating : UL 94V-2

• CSA Rating : Certified, LR 7189

• Glow Wire Rating : Standard Part - Not Glow Wire

• UL Rating : Recognized
