Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• CSA Rating : LR 7189, Certified

• Compatible With Approved Standards Products : UL E28476

• UL Rating : Recognized

• Compatible With Agency/Standards Products : UL, CSA

• UL Flammability Rating : UL 94V-0

• Connector Height : 9.4 mm [ .37 in ]

• Product Length : 52.83 mm [ 2.08 in ]

• Product Width : 36.58 mm [ 1.44 in ]

• Compatible Insulation Diameter Range : 1.02 – 25.91 mm [ .04 – 1.02 in ]

• Wire Size (AWG): 18 – 10

• Wire Size (mm²): .811 – 6.11

• Wire Size (CMA): 1600.53 – 12066.13

• Mating Alignment : With

• Mating Alignment Type : Polarization

• Mating Retention : With

• PCB Mount Retention : Without

• Mating Retention Type : Latch

• Panel Mount Feature : Without

• Rectangular Power Connector Type : Housing

• Connector & Housing Type : Plug

• Connector System : Wire-to-Board

• Sealable : No

• Connector & Contact Terminates To : Wire & Cable

• Number of Positions : 4

• Number of Power Positions : 4

• Number of Signal Positions : 0

• Number of Rows : 1

• Operating Voltage (VAC): 600

• Operating Voltage (VDC): 600

• Contact Current Rating (Max) (A): 35

• Contact Retention Within Housing : With

• Contact Type : Receptacle

• Centerline (Pitch) : 11.18 mm [ .44 in ]

• Housing Color : Black

• Housing Material : Polycarbonate

• Operating Temperature Range : 0 – 105 °C [ 32 – 221 °F ]

• Circuit Application : Power

• Packaging Method : Loose Piece
