Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Plug

• Connector System : Wire-to-Board

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Socket

• Contact Size : 1.3mm

• Mating Pin Diameter : 1.3 mm [ .051 in ]

• Contact Current Rating (Max) (A): 17

• Housing Material : PBT

• Centerline (Pitch) : 4 mm [ .157 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Gray

• Connector & Keying Code : C

• Operating Voltage (VAC): 250

• Nominal Voltage Architecture (V): 250

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : Add By Accessory

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Tray

• Packaging Quantity : 28

• Connector Height : 34.6 mm [ 1.362 in ]

• Product Length : 47.4 mm [ 1.866 in ]

• Product Width : 33.6 mm [ 1.323 in ]

• Row-to-Row Spacing : 4 mm [ .157 in ]

• UL Flammability Rating : UL 94V-0

• IP Rating : IP69K, IP67

• Number of Positions : 23

• Number of Rows : 3

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]
