D-Sub Shielded Receptacle Assembly: Right Angle, 2.16mm

D-Sub Shielded Receptacle Assembly: Right Angle, 2.16mm-CAT-063-DSRC90216
PCB D-Sub Shielded receptacle assembly with a centerline pitch of 2.16mm and right angle PCB mount orientation. Used for signal circuit application and has an operating temperature range of -40 – 105 DEGC.
More Less

Product Features

  • Connector & Housing Type : Receptacle

  • Connector System : Cable-to-Board

  • Number of Positions : 24, 50, 36

  • Centerline (Pitch) : 2.16 mm [ .085 in ]

  • Number of Rows : 2

Available from

LADD Inc
Features

Please review product documents or contact us for the latest agency approval information.

Packaging Features

  • Packaging Method  Package, Tray, Box, Tube

  • Packaging Quantity  60, 30, 10, 40, 1, 270, 17

Body Features

  • Shield Plating Finish  Bright

  • Shield Plating Material  Nickel, Nickel over Copper

  • Primary Product Color  Black

  • Shield Material  Die Cast Metal, Zinc, Copper-Zinc Alloy

  • Assembly Process Feature Material  Carbon Steel

  • Connector Profile  Low, Standard

Mechanical Attachment

  • PCB Mount Alignment  With

  • Mounting Feature Material  Thermoplastic

  • Panel Attachment Style  Rear Mount

  • Assembly Process Feature Plating Material  Tin

  • Mating Alignment  With

  • Mounting Hole Diameter (in) .125, .126, .128

  • PCB Mount Retention  With

  • PCB Mount Retention Type  Boardlock, Mounting Hole

  • Mating Retention  With

  • Mating Retention Type  4-40 Tapped Holes, Screwlocks, Bail Lock

  • Connector Mounting Type  Panel Mount & Board Mount, Board Mount, Panel Mount

Operation/Application

  • Shielded  Yes, No

  • Circuit Application  Signal

Contact Features

  • Contact Mating Area Plating Material Thickness (µm) .76

  • Contact Mating Area Plating Material Thickness (µin) 30

  • Contact Options  Installed

  • Contact Base Material  Copper Alloy

  • PCB Contact Termination Area Plating Material  Tin

  • Contact Underplating Material  Nickel, Palladium Nickel

  • Contact Mating Area Plating Material  Gold or Gold Flash, Gold

  • Contact Shape & Form  Rectangular

  • Contact Current Rating (Max) (A) 3.5

Termination Features

  • Termination Method to PCB  Through Hole - Solder

  • Rectangular Termination Post & Tail Width (mm) .56, .5

  • Rectangular Termination Post & Tail Width (in) .019, .022

  • Termination Post & Tail Length (in) .125, .09

  • Termination Post & Tail Length (mm) 3.18, 2.29

  • Termination Post & Tail Length (in) .125, .09

  • Rectangular Termination Post & Tail Thickness  .25 mm [ .01 in ]

Housing Features

  • Housing Material  Polyester GF, Polyester, Thermoplastic

  • Centerline (Pitch)  2.16 mm [ .085 in ]

Industry Standards

  • UL Flammability Rating  UL 94V-0

Dimensions

  • Panel Thickness (Recommended) (mm) 1.57, 3.18

  • Panel Thickness (Recommended) (in) .062, .125

  • PCB Thickness (Recommended) (in) .062

  • PCB Thickness (Recommended)  1.57 mm [ .062 in ]

  • Row-to-Row Spacing (mm) 4.32, 4.3

  • Row-to-Row Spacing (in) .169, .17

Product Type Features

  • Ground Feature Type  Grounding Indents

  • Connector & Housing Type  Receptacle

  • Connector System  Cable-to-Board

  • Connector & Contact Terminates To  Printed Circuit Board

Configuration Features

  • Number of Positions  24, 50, 36

  • Number of Rows  2

  • PCB Mount Orientation  Right Angle

Usage Conditions

  • Operating Temperature Range  -40 – 105 °C [ -40 – 221 °F ]

Other

  • EU RoHS Compliance  Compliant, Compliant with Exemptions, Not Compliant

  • EU ELV Compliance  Compliant, Compliant with Exemptions

Reference Number

  • TE Internal Number CAT-063-DSRC90216
