F Type Connector: Jack, Right-Angle, Elbow Jack PCB, 75 Ohm

Please review product documents or contact us for the latest agency approval information.

• Crimp Type  Hexagonal Crimping

• RF Interface  F Type

• RF Connector Style  Plug

• Compatible With RF Cable Type  RG 62A, KX 6A, Belden 9291, KX 25, RG 6, 9291, KX 52, RG 140, URM 90, CT100, RG 59B, RG 210, CT125, KX 53

• Connector System  Cable-to-Board

• Sealable  No

• Connector & Contact Terminates To  Wire & Cable

• RF Connector Mated Outer Diameter (Approximate) (mm) 11.2, 9.5

• RF Connector Mated Outer Diameter (Approximate) (in) .44, .374

• Impedance (Ω) 75

• RF Connector Coupling Mechanism  Screw

• Connector Mounting Type  Panel Mount

• RF Contact Captivation Method  Mechanical

• Detent  Without

• Operating Frequency (GHz) 1

• Number of Positions  1

• Number of Coaxial Contacts  1

• Cable Connector Orientation  Straight

• Body Material  Brass

• Body Plating Material  Nickel

• Termination Method to Wire & Cable  Crimp, Twist-On

• Packaging Method  Box

• EU RoHS Compliance  Compliant

• EU ELV Compliance  Compliant with Exemptions
