ZHD-CT LFH & Fluid Resistant Tube

ZHD-CT

Formulated to give Zero halogen properties with the added benefit of fluid resistant, ZHD-CT is designed to bridge the gap where high performance tube is required without compromising on safety or capability.

More Less

Digital Datasheet|

Product Features

Operating Temperature Range (°C): -55 – 135, -55 – 175
Operating Temperature Range (°F): -67 – 275
Primary Product Color : Yellow, White
Expanded Inside Diameter (Min) (mm): 19, 4.8, 38.1, 6.4, 9.5, 25.4, 12.7, 2.4, 3.2
Expanded Inside Diameter (Min) (in): .126, .5, .094, .189, 1.5, 1, .375, .125, .75, .25
Recovered Inside Diameter (Max) (mm): 1.2, 19, 6.4, 9.5, 12.7, 2.4, 1.6, 3.2, 4.75
Recovered Inside Diameter (Max) (in): .047, .5, .094, .062, .063, .375, .125, .75, .187, .25
Shrink Ratio : 2:1

Available from

Product	TE Part #	Documents	Primary Product Color	Expanded Inside Diameter (Min)	Recovered Inside Diameter (Max)	Compatible Cable Diameter Range	Operating Temperature Range
ZHD-CT-50M-19.0-OUT-4	EL8126-000	Product Drawing	Yellow	19 mm	9.5 mm	10.1 – 16.2 mm	-55 – 135 °C
ZHD-CT-50M-12.7-OUT-9	EL8116-000	Product Drawing	White	12.7 mm	6.4 mm	6.9 – 10.7 mm	-55 – 175 °C
ZHD-CT-50M-12.7-OUT-4	EL8125-000	Product Drawing	Yellow	12.7 mm	6.4 mm	6.9 – 10.7 mm	-55 – 135 °C
ZHD-CT-50M-6.4-OUT-4	EL8123-000	Product Drawing	Yellow	6.4 mm	3.2 mm	3.8 – 5.4 mm	-55 – 135 °C
ZHD-CT-50M-2.4-OUT-9	EL8111-000	Product Drawing	White	2.4 mm	1.2 mm	1.2 – 1.9 mm	-55 – 135 °C
ZHD-CT-50M-9.5-OUT-4	EL8124-000	Product Drawing	Yellow	9.5 mm	4.75 mm	5.5 – 8.1 mm	-55 – 135 °C
ZHD-CT-50M-4.8-OUT-4	EL8122-000	Product Drawing	Yellow	4.8 mm	2.4 mm	2.5 – 4. mm	-55 – 135 °C
ZHD-CT-50M-4.8-OUT-9	EL8113-000	Product Drawing	White	4.8 mm	2.4 mm	2.5 – 4. mm	-55 – 135 °C
ZHD-CT-50M-6.4-OUT-9	EL8114-000	Product Drawing	White	6.4 mm	3.2 mm	3.8 – 5.4 mm	-55 – 135 °C
ZHD-CT-50M-2.4-OUT-4	EL8120-000	Product Drawing	Yellow	2.4 mm	1.2 mm	1.2 – 1.9 mm	-55 – 135 °C
ZHD-CT-40M-38.1-OUT-4	EL8128-000	Product Drawing	Yellow	38.1 mm	19 mm	20.95 – 33.02 mm	-55 – 135 °C
ZHD-CT-50M-3.2-OUT-9	EL8112-000	Product Drawing	White	3.2 mm	1.6 mm	1.7 – 2.6 mm	-55 – 135 °C
ZHD-CT-50M-9.5-OUT-9	EL8115-000	Product Drawing	White	9.5 mm	4.75 mm	5.5 – 8.1 mm	-55 – 135 °C
ZHD-CT-50M-19.0-OUT-9	EL8117-000	Product Drawing	White	19 mm	9.5 mm	10.1 – 16.2 mm	-55 – 135 °C
ZHD-CT-40M-25.4-OUT-9	EL8118-000	Product Drawing	White	25.4 mm	12.7 mm	14.29 – 21.59 mm	-55 – 135 °C
ZHD-CT-40M-38.1-OUT-9	EL8119-000	Product Drawing	White	38.1 mm	19 mm	20.95 – 33.02 mm	-55 – 135 °C
ZHD-CT-50M-3.2-OUT-4	EL8121-000	Product Drawing	Yellow	3.2 mm	1.6 mm	1.7 – 2.6 mm	-55 – 135 °C
ZHD-CT-40M-25.4-OUT-4	EL8127-000	Product Drawing	Yellow	25.4 mm	12.7 mm	14.29 – 21.59 mm	-55 – 135 °C

Overview

Formulated to give Zero halogen properties with the added benefit of fluid resistant, ZHD-CT is designed to bridge the gap where high performance tube is required without compromising on safety or capability.

Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

Printable Tubing Type Continuous
Printable Tubing Grade Fluid Resistant & Low Fire Hazard

Body Features

Primary Product Color Yellow, White
Shrink Ratio 2:1

Dimensions

Expanded Inside Diameter (Min) (mm) 2.4, 3.2, 4.8, 6.4, 9.5, 12.7, 19, 25.4, 38.1
Expanded Inside Diameter (Min) (in) .094, .125, .126, .189, .25, .375, .5, .75, 1, 1.5
Recovered Inside Diameter (Max) (mm) 1.2, 1.6, 2.4, 3.2, 4.75, 6.4, 9.5, 12.7, 19
Recovered Inside Diameter (Max) (in) .047, .062, .063, .094, .125, .187, .25, .375, .5, .75
Compatible Cable Diameter Range (mm) 1.2 – 1.9, 1.7 – 2.6, 2.5 – 4., 3.8 – 5.4, 5.5 – 8.1, 6.9 – 10.7, 10.1 – 16.2, 14.29 – 21.59, 20.95 – 33.02
Compatible Cable Diameter Range (in) .05 – .075, .069 – .105, .1 – .16, .15 – .215, .22 – .32, .26 – .449, .4 – .64, .563 – .85, .825 – 1.3

Usage Conditions

Operating Temperature Range (°C) -55 – 135, -55 – 175
Operating Temperature Range (°F) -67 – 275

Printer/Label Features

Printer Technology Thermal Transfer

Packaging Features

Packaging Quantity 50

Reference Number

TE Internal Number CAT-C7679-Z614

Related Materials

No documentation available.

ZHD-CT LFH & Fluid Resistant Tube

Product Features

Operating Temperature Range (°C): -55 – 135, -55 – 175

Operating Temperature Range (°F): -67 – 275

Primary Product Color : Yellow, White

Expanded Inside Diameter (Min) (mm): 19, 4.8, 38.1, 6.4, 9.5, 25.4, 12.7, 2.4, 3.2

Expanded Inside Diameter (Min) (in): .126, .5, .094, .189, 1.5, 1, .375, .125, .75, .25

Recovered Inside Diameter (Max) (mm): 1.2, 19, 6.4, 9.5, 12.7, 2.4, 1.6, 3.2, 4.75

Recovered Inside Diameter (Max) (in): .047, .5, .094, .062, .063, .375, .125, .75, .187, .25

Shrink Ratio : 2:1

Product Type Features

Printable Tubing Type Continuous

Printable Tubing Grade Fluid Resistant & Low Fire Hazard

Body Features

Primary Product Color Yellow, White

Shrink Ratio 2:1

Dimensions

Expanded Inside Diameter (Min) (mm) 2.4, 3.2, 4.8, 6.4, 9.5, 12.7, 19, 25.4, 38.1

Expanded Inside Diameter (Min) (in) .094, .125, .126, .189, .25, .375, .5, .75, 1, 1.5

Recovered Inside Diameter (Max) (mm) 1.2, 1.6, 2.4, 3.2, 4.75, 6.4, 9.5, 12.7, 19

Recovered Inside Diameter (Max) (in) .047, .062, .063, .094, .125, .187, .25, .375, .5, .75

Compatible Cable Diameter Range (mm) 1.2 – 1.9, 1.7 – 2.6, 2.5 – 4., 3.8 – 5.4, 5.5 – 8.1, 6.9 – 10.7, 10.1 – 16.2, 14.29 – 21.59, 20.95 – 33.02

Compatible Cable Diameter Range (in) .05 – .075, .069 – .105, .1 – .16, .15 – .215, .22 – .32, .26 – .449, .4 – .64, .563 – .85, .825 – 1.3

Usage Conditions

Operating Temperature Range (°C) -55 – 135, -55 – 175

Operating Temperature Range (°F) -67 – 275

Printer/Label Features

Printer Technology Thermal Transfer

Packaging Features

Packaging Quantity 50

Reference Number

TE Internal Number CAT-C7679-Z614
