M85049/82 Unscreened, Banding Backshells
Mil-Spec /82 banding backshells with self-locking coupling features aluminum with olive drab finish.
Product Features
-
Connector Backshell Product Style : Unscreened
-
Connector Backshell Product Type : Backshell
-
Primary Product Material : Aluminum Alloy
-
Body Orientation : Straight
-
Compatible With Connector Shell Size : 8, 12, 10, 18, 14
Overview
Features
Please review product documents or contact us for the latest agency approval information.
Contact Features
-
Primary Product Underplating Material Electroless Nickel
Dimensions
-
Product Length 42.16 mm [ 1.66 in ]
Product Type Features
-
Connector Backshell Product Style Unscreened
-
Connector Backshell Product Type Backshell
-
Sealable No
Body Features
-
Primary Product Material Aluminum Alloy
-
Primary Product Plating Material Cadmium
Housing Features
-
Body Orientation Straight
-
Compatible With Connector Shape Circular
Operation/Application
-
Compatible With Connector Shell Size 8, 12, 10, 18, 14
Other
-
Connector Interface Specification MIL-DTL-26482 Series II, AS81703 Series 3, MIL-DTL-83723 / SERIES III, AS50151 Crimp Contact
-
EU RoHS Compliance Not Compliant
-
EU ELV Compliance Compliant, Not Compliant
Usage Conditions
-
Operating Temperature Range -65 – 175 °C [ -85 – 347 °F ]
Reference Number
-
TE Internal Number CAT-R85049-1I
