• Blank Cavity Position : 0

• Number of Positions : 8

• Number of Rows : 2

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Male Terminals

• Connector System : Wire-to-Panel

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Pin

• Contact Size : Size 16

• Mating Pin Diameter : 1.6 mm [ .062 in ]

• Contact Current Rating (Max) (A): 13

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Strain Relief : Without

• Connector Mounting Type : Panel Mount

• Packaging Method : Package

• Packaging Quantity : 1

• Connector Height : 45.7 mm [ 1.79 in ]

• Product Length : 55 mm [ 2.16 in ]

• Product Width : 35.5 mm [ 1.39 in ]

• Compatible Insulation Diameter Range : 2.2 – 3.7 mm [ .088 – .145 in ]

• UL Flammability Rating : 12mm Flame Test per Standard UL-94

• Compatible With Agency/Standards Products : SAE J2030

• IP Rating : IP6K9K, IP68

• Housing Material : PA 66 GF15

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
