Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Wire & Cable

• Connector & Housing Type : Receptacle

• Primary Locking Feature : Integrated in Housing

• Sealable : Yes

• Connector Shape : Rectangular

• Connector System : Wire-to-Panel

• Mixed & Hybrid Connector : No

• Number of Rows : 2

• Connector Seal Code : N Seal

• Number of Positions : 4

• Blank Cavity Position : 0

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Primary Product Color : Black

• Cable Exit Angle : 180°

• Mating Pin Diameter : 1.6 mm [ .063 in ]

• Contact Current Rating (Max) (A): 13

• Contact Type : Pin

• Contact Size : Size 16

• Connector Mounting Type : Panel Mount

• Terminal Position Assurance : No

• Strain Relief : Without

• Mating Alignment Type : Polarized

• Mating Alignment : With

• Housing Material : PA66 GF15

• Product Width : 31.7 mm [ 1.25 in ]

• Connector Height : 45.9 mm [ 1.8 in ]

• Row-to-Row Spacing : 9.12 mm [ .359 in ]

• Compatible Insulation Diameter Range : 1.4 – 3.8 mm [ .055 – .15 in ]

• Product Length : 40.5 mm [ 1.59 in ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Circuit Application : Power

• Compatible With Agency/Standards Products : SAE J2030

• UL Flammability Rating : UL 94V-0

• Degree of Protection : IP6K9K, IP68

• Packaging Method : Package

• Packaging Quantity : 1
