Please review product documents or contact us for the latest agency approval information.

• Connector & Contact Terminates To : Wire & Cable

• Connector & Housing Type : Housing for Female Terminals

• Primary Locking Feature : Integrated in Housing

• Sealable : Yes

• Connector Shape : Triangular

• Connector System : Component-to-Wire

• Mixed & Hybrid Connector : No

• Number of Rows : 2

• Number of Positions : 3

• Connector Modification : Terminating Resistor, End Cap, J1939

• Blank Cavity Position : 0

• Operating Voltage (VDC): 250

• Nominal Voltage Architecture (V): 250

• Operating Voltage (VAC): 250

• Primary Product Color : Black

• Cable Exit Angle : 180°

• Mating Pin Diameter : 1.59 mm [ .063 in ]

• Contact Current Rating (Max) (A): 13

• Contact Type : Socket

• Contact Size : Size 16

• Terminal Position Assurance : Yes

• Strain Relief : Add By Accessory

• Mating Alignment Type : Polarized

• Mating Alignment : With

• Centerline (Pitch) : 8.66 mm [ .341 in ]

• Housing Material : PA GF

• Product Width : 18.71 mm [ .737 in ]

• Connector Height : 24.38 mm [ .96 in ]

• Product Length : 29.67 mm [ 1.168 in ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Circuit Application : Power

• Compatible With Agency/Standards Products : SAE J2030

• UL Flammability Rating : Not tested

• Degree of Protection : IP6K9K, IP68

• Packaging Method : Box

• Packaging Quantity : 1000
