Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Blank Cavity Position : 0

• Number of Positions : 4

• Number of Rows : 2

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Male Terminals

• Connector System : Bus Bar-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable, Bus Bar

• Contact Type : Pin

• Mating Pin Diameter : 1.59 mm [ .063 in ]

• Contact Current Rating (Max) (A): 13

• Housing Material : PA GF

• Centerline (Pitch) : 4.45 mm [ .175 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Nominal Voltage Architecture (V): 250

• Serviceable : No

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant with Exemptions

• EU ELV Compliance : Compliant with Exemptions

• Mating Alignment Type : Polarization

• Terminal Position Assurance : No

• Connector Mounting Type : Bus Bar Mount

• UL Flammability Rating : Not tested

• Compatible With Agency/Standards Products : SAE J2030

• IP Rating : IP6K9K, IP68

• Row-to-Row Spacing : 9.12 mm [ .359 in ]

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
