Next Generation Form Factor is Here
The M.2 Next Generation Form Factor (NGFF) product line is a natural transition from the mini card and half-mini card to a smaller form factor in both size and volume. WiFi, Bluetooth, global navigation satellite systems, near field communication, hybrid digital radio, Wireless Gigabit Alliance (WiGig), wireless Wide Area Network, and solid-state storage devices. It also adds functionality to PCIe Gen 3, SATA 3, SATA I/O, and USB 3.0. The new, smaller form factor is suitable for applications in new thin platforms.
Product Features:
M.2 Connectors
- 0.5mm pitch with 67 positions
- Designed for both single- and double-sided modules
- Available in various keying options for module cards
- Support PCI Express 3.0, USB 3.0, and SATA 3.0
- Choice in height, position, design, and keying option
- Available in various heights
Featured Applications
M.2 Connectors
As the market shifts toward slimmer solutions, we see M.2 (NGFF) products as the natural transition from the PCI express mini card to a smaller, standardized form factor.
- Jaren May,
- Product Manager, Consumer Devices
M.2 NGFF product line is a natural transition from the mini card and half mini card to a smaller form factor in both size and volume.
