Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Wall Type : Single Wall

• Operating Voltage (Max) (kV): .6

• Primary Product Color : Yellow

• Flexibility : Flexible

• Primary Product Material : Irradiated Modified Polyolefin

• Shrink Ratio : 3:1

• Fluid Type : Gasoline, Hydraulic Fluid, Lubricating Oil

• Tubing Size Range : 13 – 39 mm [ .512 – 1.535 in ]

• Expanded Inside Diameter (Min) : 39 mm [ 1.535 in ]

• Recovered Inside Diameter (Max) : 13 mm [ .512 in ]

• Recovered Wall Thickness (Tolerance) : .25 mm [ .01 in ]

• Recovered Wall Thickness (Nominal) : 1.15 mm [ .045 in ]

• Operating Temperature Range (°C): -40 – 135

• Recovery Temperature (°C): 120

• Tubing Flammability Type : Flame-Retardant

• Shrink Temperature (Min) (°C): 80

• Mechanical Resistance : Strain Relief, Mechanical Damage, Fluids

• Applicable Region : EMEA, Asia

• Packaging Method : Box
