Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Coating Style : Spiral, Planar

• Installation Technology : Heat Shrink

• Adhesive Coating : With

• Wall Style (Excluding Adhesive) : Single

• Wall Thickness : Thick/Heavy

• Compatible Cable Diameter - Body (Min) : 14 mm [ .551 in ]

• Compatible Cable Diameter - Body (Max) : 34 mm [ 1.338 in ]

• Compatible Cable Diameter - Leg (Min) : 5 mm [ .196 in ]

• Compatible Cable Diameter - Leg (Max) : 14 mm [ .551 in ]

• Expanded Inside Diameter (Min) (Body) : 38 mm [ 1.496 in ]

• Expanded Inside Diameter (Min) (Leg) : 16 mm [ .629 in ]

• Leg Length : 28 mm [ 1.102 in ]

• Overall Product Length : 103 mm [ 4.055 in ]

• Recovered Inside Diameter (Max) (Body) : 13 mm [ .511 in ]

• Recovered Inside Diameter (Max) (Leg) : 4.2 mm [ .165 in ]

• Recovered Wall Thickness (Max) (Body) : 2.7 mm [ .106 in ]

• Recovered Wall Thickness (Max) (Leg) : 1.5 mm [ .059 in ]

• Body Length : 45 mm [ 1.771 in ]

• Primary Product Material : Crosslinked Polyolefin

• Primary Product Color : Black

• Flexibility : Semi-Rigid

• Shrink Ratio : > 2.5:1

• Packaging Quantity : 10

• Environmental Resistance : Salt Water, Weathering, Contaminated Water, Rain, Moisture

• Fluid Resistance Type : Hydrocarbons, Transformer Oil

• Flammability Performance : Non-Flame-Retardant

• Thermal Resistance : Applicable for Low Temperatures, Applicable for High Temperatures, Flame-Retardant

• UV-Stabilized : Yes

• Mechanical Resistance : Against Mechanical Impact

• Voltage Class (kV): ≤ 1

• Product Availability : Asia, Australia, New Zealand & Pacific Islands, Europe, Middle East & Africa, Americas

• Number of Branches & Legs : 3
