Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Board, Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : 1.6mm, 4.8mm

• Mating Tab Width (mm): 4.8, 1.6

• Mating Tab Width (in): .189, .063

• Contact Current Rating (Max) (A): 14, 35

• Housing Material : PBT GF

• Centerline (Pitch) : 4 mm [ .157 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Blue

• Connector & Keying Code : A

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Strain Relief : Add By Accessory

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Box

• Connector Height : 34.1 mm [ 1.34 in ]

• Product Length : 82.4 mm [ 3.24 in ]

• Product Width : 33.5 mm [ 1.31 in ]

• Row-to-Row Spacing : 8.9 mm [ .35 in ]

• UL Flammability Rating : UL 94HB

• IP Rating : IP67

• Number of Positions : 26

• Number of Rows : 2

• Nominal Voltage Architecture (V): 16

• Operating Temperature (Max) : 100 °C [ 212 °F ]

• Operating Temperature Range : -40 – 100 °C [ -40 – 212 °F ]
