1-1718484-4
25 Position, Blue, Cover Assembly, PBT GF, 180° Cable Exit, -40 – 120 °C [-40 – 248 °F], AMP MCP Connector System
1-1718484-4
25 Position, Blue, Cover Assembly, PBT GF, 180° Cable Exit, -40 – 120 °C [-40 – 248 °F], AMP MCP Connector System
-
- AMP
- AMP MCP Connector System
- TE Internal #: 1-1718484-4
- TE Internal Description: CARRIER FOR RECEPTACLE INSERTS
- All AMP Carrier for Receptacle Inserts (14)
-
Number of Positions : 25
-
Primary Product Color : Blue
-
Protection & Strain Relief Accessory Type : Cover Assembly
-
Primary Product Material : PBT GF
-
Cable Exit Angle : 180°
Documents
Product Drawings
- CARRIER FOR AMP MCP1.5K/2.8 Buchseneinsaetze, 18+7pol. ENG_CD_1718484_D1.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_1-1718484-4_D_c-1-1718484-4-d-3d.pdf 3D
- Customer View Model ENG_CVM_CVM_1-1718484-4_D_c-1-1718484-4-d.2d_dxf.zip English
- ENG_CVM_CVM_1-1718484-4_D_c-1-1718484-4-d.3d_igs.zip English
- ENG_CVM_CVM_1-1718484-4_D_c-1-1718484-4-d.3d_stp.zip English
Product Specifications
- Application Specification GER_SS_114-18663_B.pdf German
- Product Specification ENG_SS_108-18957_B.pdf English
