Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Housing Material : Nylon 66 GF

• Centerline (Pitch) : 3.5 mm [ .137 in ]

• Contact Mating Area Plating Material Thickness : .38 µm [ 15 µin ]

• Contact Mating Area Plating Material : Gold

• Contact Type : Pin

• Contact Current Rating (Max) (A): 4

• Mating Alignment Type : Keyed

• PCB Mount Retention Type : Retention Leg

• Mating Retention : With

• PCB Mount Retention : With

• PCB Mount Alignment : Without

• Connector Mounting Type : Board Mount

• Mating Alignment : With

• PCB Connector Assembly Type : PCB Mount Header

• Connector System : Wire-to-Board

• Header Type : Fully Shrouded

• Sealable : No

• Connector & Contact Terminates To : Printed Circuit Board

• PCB Mount Orientation : Vertical

• Number of Positions : 8

• Number of Rows : 2

• Primary Product Color : Black

• Termination Method to PCB : Through Hole - Solder

• Operating Temperature Range : -30 – 105 °C [ -22 – 221 °F ]

• Circuit Application : Power & Signal

• UL Flammability Rating : UL 94V-0

• Packaging Method : Tube
