Please review product documents or contact us for the latest agency approval information.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Male Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : On the Terminal

• Connector & Contact Terminates To : Wire & Cable

• Blank Cavity Position : 0

• Number of Positions : 4

• Number of Rows : 2

• Nominal Voltage Architecture (V): 25, 48

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Connector & Keying Code : A

• Contact Type : Tab

• Contact Size : 1.2mm

• Mating Tab Width (mm): .6

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : With

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Housing Material : PA GF, PBT GF

• Centerline (Pitch) (mm): 4

• Row-to-Row Spacing (mm): 4

• Operating Temperature (Max) (°C): 150

• Operating Temperature Range : -40 – 150 °C [ -40 – 302 °F ]

• Circuit Application : Signal
