Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Wire & Cable

• Connector Shape : Rectangular

• Connector & Housing Type : Housing for Female Terminals

• Primary Locking Feature : On the Terminal

• Sealable : No

• Connector System : Wire-to-Wire

• Mixed & Hybrid Connector : No

• Number of Positions : 4

• Number of Rows : 1

• Operating Voltage (VDC): 14

• Nominal Voltage Architecture (V): 12

• Primary Product Color : Black

• Connector & Keying Code : A

• Cable Exit Angle : 180°

• Mating Tab Width : 2.8 mm [ .11 in ]

• Contact Current Rating (Max) (A): 30

• Contact Size : 2.8mm

• Contact Type : Receptacle

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Mating Alignment : With

• Strain Relief : Without

• Housing Material : PBT GF

• Centerline (Pitch) : 5 mm [ .197 in ]

• Product Width : 37.75 mm [ 1.486 in ]

• Connector Height : 19 mm [ .748 in ]

• Product Length : 36.7 mm [ 1.445 in ]

• Operating Temperature Range : -40 – 120 °C [ -40 – 248 °F ]

• Operating Temperature (Max) (°C): 70, 75, 80, 85, 90, 100, 105, 110, 120

• Operating Temperature (Max) (°F): 158, 167, 176, 185, 194, 212, 221, 230, 248

• Circuit Application : Power

• UL Flammability Rating : UL 94HB

• Packaging Method : Bag
