Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Coating Style : Spiral

• Installation Technology : Heat Shrink

• Adhesive Coating : With

• Wall Style (Excluding Adhesive) : Single

• Wall Thickness : Thick/Heavy

• Compatible Cable Diameter - Body (Min) : 28 mm [ 1.102 in ]

• Compatible Cable Diameter - Body (Max) : 77 mm [ 3.031 in ]

• Compatible Cable Diameter - Leg (Min) (mm): 8, 7

• Compatible Cable Diameter - Leg (Min) (in): .315, .276

• Compatible Cable Diameter - Leg (Max) (mm): 24, 30

• Compatible Cable Diameter - Leg (Max) (in): .945, 1

• Expanded Inside Diameter (Min) (Body) : 85 mm [ 3.346 in ]

• Expanded Inside Diameter (Min) (Leg) : 33 mm [ 1.299 in ]

• Leg Length : 40 mm [ 1.574 in ]

• Overall Product Length : 180 mm [ 7.086 in ]

• Recovered Inside Diameter (Max) (Body) : 26 mm [ 1.023 in ]

• Recovered Inside Diameter (Max) (Leg) (mm): 7, 6

• Recovered Inside Diameter (Max) (Leg) (in): .236, .276

• Recovered Wall Thickness (Max) (Body) : 3.2 mm [ .125 in ]

• Recovered Wall Thickness (Max) (Leg) : 2.2 mm [ .086 in ]

• Body Length : 75 mm [ 2.952 in ]

• Primary Product Material : Crosslinked Polyolefin

• Primary Product Color : Black

• Flexibility : Semi-Rigid

• Shrink Ratio : > 2.5:1

• Packaging Quantity : 5

• Environmental Resistance : Salt Water, Weathering, Contaminated Water, Rain, Moisture

• Fluid Resistance Type : Hydrocarbons, Transformer Oil

• Flammability Performance : Non-Flame-Retardant

• Thermal Resistance : Applicable for Low Temperatures, Applicable for High Temperatures, Flame-Retardant

• UV-Stabilized : Yes

• Mechanical Resistance : Against Mechanical Impact

• Voltage Class (kV): ≤ 1

• Product Availability : Asia, Europe, Middle East & Africa, Australia, New Zealand & Pacific Islands, Americas

• Number of Branches & Legs : 5
