Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Connector Seal & Plug Type : Wire Entry Seal

• Connector Product Type : Housing

• Connector System : Wire-to-Wire

• Sealable : Yes

• Connector & Contact Terminates To : Wire & Cable

• Connector & Housing Type : Plug

• Circular Connector Shell Type : All Plastic

• Number of Positions : 4

• Number of Power Positions : 0

• Number of Signal Positions : 4

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Reverse Gender : No

• Contact Type : Socket

• Contact Current Rating (Max) (A): 7.5

• Termination Method to Wire & Cable : Crimp

• Mating Alignment : With

• Thread Size : 1/2-20 UNF-2A

• Mating Retention Type : Threaded Coupling

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Retention : With

• Panel Mount Feature : Without

• Housing Color : Black

• Housing Material : Thermoplastic

• Circular Connector Shell Size : 8

• Compatible Insulation Diameter Range : .89 – 1.5 mm [ .035 – .059 in ]

• Wire Size (AWG): 30 – 18

• Wire Size (mm²): .0509 – .823

• Operating Temperature Range : -55 – 105 °C [ -67 – 221 °F ]

• Fluid Resistance : Immersion

• Circuit Application : Power & Signal

• Shielded : No

• UL Flammability Rating : UL 94V-0
