Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Wire & Cable

• Connector Shape : Rectangular

• Connector & Housing Type : Housing for Male Terminals

• Primary Locking Feature : On the Terminal

• Sealable : No

• Connector System : Wire-to-Wire

• Mixed & Hybrid Connector : No

• Number of Positions : 2

• Number of Rows : 1

• Operating Voltage (VDC): 14

• Nominal Voltage Architecture (V): 12, 24

• Primary Product Color : Black

• Connector & Keying Code : Neutral

• Cable Exit Angle : 180°

• Contact Current Rating (Max) (A): 7.5

• Contact Size : .64mm

• Contact Type : Tab

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Alignment Type : Polarizing Slot

• Terminal Position Assurance : Yes

• Mating Alignment : With

• Strain Relief : Without

• Housing Material : PA GF

• Centerline (Pitch) : 2.54 mm [ .1 in ]

• Product Width : 35 mm [ 1.378 in ]

• Connector Height : 10.3 mm [ .406 in ]

• Product Length : 10.95 mm [ .431 in ]

• Operating Temperature Range : -40 – 120 °C [ -40 – 248 °F ]

• Operating Temperature (Max) : 120 °C [ 248 °F ]

• Circuit Application : Signal

• Packaging Method : Package

• Packaging Quantity : 2000
