Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Male Terminals

• Connector System : Wire-to-Wire

• Sealable : No

• Primary Locking Feature : On the Terminal

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Tab

• Contact Size : .63mm

• Mating Tab Width : .64 mm [ .025 in ]

• Housing Material : PBT

• Centerline (Pitch) : 2.2 mm [ .087 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Natural

• Operating Voltage (VDC): 12

• Nominal Voltage Architecture (V): 12

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Polarized

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Bag

• Packaging Quantity : 100

• Connector Height : 15.8 mm [ .622 in ]

• Product Length : 35.2 mm [ 1.386 in ]

• Product Width : 40.6 mm [ 1.598 in ]

• Row-to-Row Spacing : 4.24 mm [ .167 in ]

• UL Flammability Rating : UL 94HB

• Number of Positions : 32

• Number of Rows : 2

• Operating Temperature (Max) : 80 °C [ 176 °F ]

• Operating Temperature Range : -30 – 80 °C [ -22 – 176 °F ]
