Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Illuminated : Without

• Switch Connection Type : Printed Circuit Board

• Leg Style : SMD Pads

• Actuator Style : Round Actuator

• ESD Grounding Terminal : Without

• Switch Feedback Type : Tactile

• Operating Function : Off (On)

• Support Bracket : With

• Configuration (Pole-Throw) : Single Pole - Single Throw

• Number of Actuators : Single

• Operating Voltage (VDC): 24

• Actuator Force : 130 g [ 4.58 oz ]

• Cover Material : Nickel, Silver

• Actuator Material : Thermoplastic

• Case Color : Black

• Case Material : Thermoplastic

• Product Orientation : Right Angle

• Actuator Color : Black

• Contact Current Rating (mA): 50

• Contact Base Material : Stainless Steel

• Switch Contact Plating Material : Silver

• Termination Method to PCB : Surface Mount

• Process Sealed : Yes

• Operating Temperature Range (°C): -35 – 85

• IP Rating : IP67
