• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Cap

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Pin

• Contact Size : 1.5mm

• Mating Pin Diameter : 1.5 mm [ .059 in ]

• Housing Material : PBT GF15

• Centerline (Pitch) : 5.3 mm [ .209 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Connector & Keying Code : D

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Bag

• Packaging Quantity : 175

• Connector Height : 22.45 mm [ .883 in ]

• Product Length : 24.6 mm [ .968 in ]

• Product Width : 47.55 mm [ 1.872 in ]

• Row-to-Row Spacing : 4.5 mm [ .177 in ]

• UL Flammability Rating : UL 94HB

• IP Rating : IP67

• Operating Voltage (VDC): 250

• Number of Positions : 4

• Number of Rows : 2

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]
