Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Wire & Cable

• Connector & Housing Type : Housing for Male Terminals

• Primary Locking Feature : Integrated in Housing

• Sealable : Yes

• Connector Shape : Rectangular

• Connector System : Wire-to-Wire

• Mixed & Hybrid Connector : No

• Number of Rows : 2

• Number of Positions : 6

• Operating Voltage (VDC): 250

• Primary Product Color : Black

• Connector & Keying Code : B

• Cable Exit Angle : 180°

• Mating Pin Diameter : 1.5 mm [ .062 in ]

• Contact Current Rating (Max) (A): 13

• Contact Type : Pin

• Contact Size : Size 16

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Mating Alignment Type : Keyed

• Mating Alignment : With

• Centerline (Pitch) : 4.5 mm [ .177 in ]

• Housing Material : PBT GF15

• Product Width : 47.55 mm [ 1.87 in ]

• Connector Height : 26.6 mm [ 1.05 in ]

• Row-to-Row Spacing : 5.3 mm [ .209 in ]

• Compatible Insulation Diameter Range : 2.2 – 3.9 mm [ .086 – .153 in ]

• Wire Size (AWG): 20 – 14

• Product Length : 24.6 mm [ .968 in ]

• Wire Size (mm²): .5 – 2

• Operating Temperature Range : -40 – 125 °C [ -40 – 257 °F ]

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Circuit Application : Power

• UL Flammability Rating : UL 94HB

• Degree of Protection : IP67

• Packaging Method : Bag

• Packaging Quantity : 50
