Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : No

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : 1mm

• Mating Tab Width (mm): 1, 1.8

• Mating Tab Width (in): .039, .071

• Housing Material : PBT

• Centerline (Pitch) (mm): 8.5, 3.5

• Centerline (Pitch) (in): .13, .33

• Cable Exit Angle : 180°

• Primary Product Color : Gray

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Polarized

• Terminal Position Assurance : No

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Connector Height : 26.25 mm [ 1.03 in ]

• Product Length : 43.8 mm [ 1.72 in ]

• Product Width : 24.3 mm [ .95 in ]

• Row-to-Row Spacing : 5.2 mm [ .2 in ]

• Packaging Quantity : 50

• Number of Positions : 15

• Number of Rows : 2

• Operating Temperature (Max) : 105 °C [ 221 °F ]

• Operating Temperature Range : -30 – 105 °C [ -22 – 221 °F ]
